High-pressure steel wire braided hose
We Support Customized Services
Regardless Of Material And Model Please Tell Me Your Needs
- 产品描述
- 符合标准
-
Construction
This hose consists of an inner tube of oil synthetic rubber, a single wire braid reinforcement, and an oil and weather resistant synthetic rubber cover.
Applications
Hose range suitable to carry hydraulic fluids such as glycol, mineral oils, fuels,lubricants, emulsion, hydrocarbons etc.
Working Temperature
from -20℃ up to +80℃
Product Parameters
Hose size I.D R.D O.D W.P P.P B.P Min B.R W.T mm Inch mm mm mm Mpa Psi Mpa Psi Mpa Psi mm Kg/m 1-6-32 1/4 6±0.5 11.5±0.6 13+1.0-0.8 32 2898 30 4347 60 8694 100 0.34 01-8-28 5/16 8±0.5 13.7±0.6 15.5+1.0-0.8 28 2536 26.25 3804 52.5 7607 115 0.41 01-10-26 3/8 10±0.5 15.7±0.6 17.5+1.0-0.8 26 2318 24 3478 48 6955 130 0.47 1-13-23 1/2 13±0.5 19.7±0.6 22+1.2-0.8 23 2028 21 3043 42 6086 180 0.67 1-16-18 5/8 16±0.5 22.7±0.8 24.5+1.2-1.0 18 1739 18 2608 36 5246 205 0.70 1-19-15 3/4 19±0.5 25.7±0.8 28+1.2-1.0 15 1449 15 2174 30 4347 240 0.84 1-22-13 7/8 22±0.5 28.7±0.8 31+1.2-1.0 13 1304 13.5 1956 27 3912 280 0.95 1-25-12 1 25±0.5 31.8±0.8 34+1.2-1.0 12 1159 12 1739 24 3478 300 1.09 1-32-10 11/4 32±0.5 38.5±0.8 41+1.2-1.0 10 869 9 1304 18 2608 420 1.38 1-38-7 11/2 38±0.7 45.0±0.8 48+1.5-1.2 7 725 7 1087 15 2174 500 1.80 1-51-5 2 51±0.7 58.2±0.8 62+1.5-1.2 5 579 6 8694 12 1739 630 2.80 1-64-4 21/2 64±1.0 71±0.8 75±1.5 4 362 3.75 543 7.5 1087 770 4.00 1-76-4 3 76±1.0 84±0.8 88±1.5 4 217 2.25 326 4.5 652 930 5.50 1-89-3 31/2 89±1.0 99±0.8 104±1.5 3 144.9 1.5 217 3 438 1100 7.60 1-102-3 4 102±1.0 110±0.8 115±1.5 3 116 1.2 174 2.4 348 1250 9.00 1-127-2 5 127±1.5 135±1.0 141±1.5 2 145 1.5 217 3 435 1350 5.68
Hebei Longzhong Rubber Products Co., Ltd.'s leading products include high-pressure steel wire braided rubber hoses, high-pressure steel wire wrapped rubber hoses, high-pressure oil drilling rubber hoses, marine high-pressure oil delivery rubber hoses, steel wire braided steam rubber hoses, steel wire braided sandblasting rubber hoses, acid and alkali resistant rubber hoses, large-diameter steel wire skeleton exhaust and suction rubber hoses, fuel rubber hoses, etc; Buckle type hose fittings, quick couplings, special hose products, etc. The product has been continuously inspected and qualified by the National Quality Inspection Bureau for many years, meeting or exceeding the requirements of national and relevant industry standards, and has been issued a production license and a coal safety mark approval certificate.
The main features of Hebei Longzhong Rubber Products Co., Ltd.'s products are: reasonable structural design, stable and reliable quality, good medium resistance, outstanding heat resistance, aging resistance, and flexural resistance, high pressure resistance, and superior pulse performance; The product is widely used in fields such as coal mining, petroleum, engineering machinery, chemical industry, machine tool equipment, hydraulics, electricity, metallurgy, agricultural machinery, etc. It is used to transport petroleum based liquids, water-based liquids, gases and other media with certain pressure and temperature, and to achieve pressure transmission and medium transportation.
